My report from the technical conference.

This was the session where I mentioned ahead of time that I had a heart-rending decision to make. Fortunately, it was made for me.

I went to The new X++ compiler and the Microsoft Dynamics AX development platform with Peter Villadsen and Robert Badawy but it was completely full.

So I then went to Deep dive into Microsoft Dynamics AX packages and extensions with Joris de Gruyter. That had also been threatening to fill up, but they moved him to a bigger room.

Choice made, by default. I mean, everyone needs and wants this session! Go look it up!

Customizations = overlayering

Extensions

Some customers have reimplemented

Agenda

• Model Store > Packages > Layers > Models
• Customizations vs Extensions
• Extension Scenarios
• Upgrading to Extensions
• Tips and Tricks
• Extensions into the Future

Model Store > Packages > Layers > Models

• Layers and models are a design-time concept only; they mean nothing at runtime
• A package is one independent, individual set of layers and models; we are now compiling directly to dll’s
• A package is a set of folders, consisting of XML files representing the objects; XMLs sit in a folder according to the package and model they’re in

• A package as a whole translates 1:1 with a unit of compilation, i.e. an assembly (DLL)
• Packages can have references to other packages, just like .NET assemblies can reference each other. But they cannot be circular
• One or more packages combine into a deployable package, i.e. a unit of deployment

Demo: Packages, files and folders

“Model view” breaks it out by model

J:\AOSService\PackagesLocalDirectory\<Package>\<Model>

Descriptor folder is like the model manifest

Customizations vs Extensions

• Customizing (“over-layering”)
  • Granularity of over-layering is down to the property level. So different customizations can change different properties on the same control. You’ll never want to over-layer a menu.
  • “Delta” files store changes only, with their original value
• Models technically also “over-layer” each other
  • No more “traditional” model conflicts, only over-layering
  • Model conflicts don’t require changing the model’s contents
  • Over-layering granularity avoids most conflicts

Demo: Customizing, overlayering concepts, delta files

Project can only be in one model

Right click on the object and select customize or create extension

The XML stores both “original” and “yours” – if an ISV sends a hotfix, you now have a three way compare

Search bar: CF: = conflicts. Right click and resolve code conflicts

If you customize thru overlayering, upgrades will be far easier

Customizations vs extensions

• Extensions are the new customizations (however going to pure extensions is near impossible)
• Extension enablers
  • Events, metadata extension features, extension methods
• Extension packages
  • Benefits on a code base short and long term
  • Package split impact on customizations
• Change your extension suffix

Q: Can you turn an extension off? A: No
Demo: Extensions, capabilities

Everything extends platform, then foundation, then application suite

We use a lot of attributes

Name is: form.extension

Can rename to form.NewExtension

You can open an element in a specific project, package, etc. and that affects what you see.

Hierarchy of models? Last one installed wins

Extension Scenarios

• Adding table fields, UI changes
  • Table extensions, form extensions, data entity extensions
• Pre / post and other event handlers
  • Table event handlers, UI event handlers, traditional pre/post and [hookable]
• Customization / extension hybrids
  • Customize based on extension artifacts, delegates
• Plugins
  • Make your code extensible
• “Package split” effects
  • Customize multiple packages
• If a method is private, you can’t do event handlers on it unless you make it hookable.
• Plugins are like the extension framework in 2012

Upgrading to Extensions

• New artifacts vs customized artifacts
  • Moving new artifacts has consequences
• Refactor vs upgrade
• Current limitations
  • Queries (you can’t really extend a query), over-layering extensions
• Security
  • Roles, duties – not privileges (you can’t extend privileges)

Tips and tricks

• Metadata search
• Go to form BaseForm
• Quick way to move a control on a form is cut and paste
• Tags
• Visual Studio has bookmarks
• Projects are not in your AOT; they’re just files in your file system
• Reports don’t allow extensions
• Element IDs are unnecessary now

Shout out to Yagesh! And sorry if I spelled your name wrong. Thanks for saying hi.

Happy DAXing!
